Metal Detector - LS-MB

Applicable to the following Industries

Food, pharmacy, textile, garment, shoemaking, toy, rubber, resources recycling, sports equipment ....industries.

Feature

1. Various kinds of tunnel dimensions and shapes are available for different kinds of goods-to-be-tested.

2. Various corresponding models for dry or wet goods-to-be-tested.

3. The detector unit can be installed properly on existing production lines. Besides, complete sets with various kinds of conveyor belt are also available.

4. Compatible with any brand of rejector, which is for getting rid of unqualified product.

5. Providing the models with computer interface, which could be integrated with the FA production management.

SPECIFICATIONS

Rejector interface

Dry contact (relay) for driving ejector,elay time and sustain time are adjustable continuously.

---

Platform height

74cm

---

Alarm singling

Buzzer ringing / Red LED lighting / belt stop or rejector start

---

Conveyor speed

Adjustable speed from 1 to 40 m/minute

---

Load capacity

Suitable for weight less than 25 kg

---

Power supply

220V single phase

---

Power consumption

Around 100 W

---

Applicable Detectors & Brief Specs

MD	Aperture Dimensions		Sensitivity
Model	Width	Height	FE	CU	SUS (316)
MD2525	25 cm	25 cm	Ø 0.8 mm	Ø 1.2 mm	Ø 1.8 mm
MD3214	32 cm	14 cm	Ø 0.7 mm	Ø 1.0 mm	Ø 1.6 mm
MD3217	32 cm	17 cm	Ø 0.8 mm	Ø 1.5 mm	Ø 1.8 mm
MD3220	32 cm	20 cm	Ø 1.0 mm	Ø 1.5 mm	Ø 2.0 mm
MD3232	32 cm	32 cm	Ø 1.2 mm	Ø 2.0 mm	Ø 2.5 mm
MD4510	45 cm	10 cm	Ø 0.7 mm	Ø 1.2 mm	Ø 1.5 mm
MD4514	45 cm	14 cm	Ø 0.8 mm	Ø 1.5 mm	Ø 1.8 mm
MD4517	45 cm	17 cm	Ø 1.0 mm	Ø 1.5 mm	Ø 2.0 mm
MD4520	45 cm	20 cm	Ø 1.2 mm	Ø 1.8 mm	Ø 2.38 mm
MD4527	45 cm	27 cm	Ø 1.5 mm	Ø 2.5 mm	Ø 3.0 mm
MD4532	45 cm	32 cm	Ø 1.8 mm	Ø 3.0 mm	Ø 3.5 mm
MD6210	62 cm	10 cm	Ø 0.8 mm	Ø 1.2 mm	Ø 1.8 mm
MD6214	62 cm	14 cm	Ø 1.0 mm	Ø 1.8 mm	Ø 2.38 mm
MD6217	62 cm	17 cm	Ø 1.5 mm	Ø 2.0 mm	Ø 3.0 mm
MD6220	62 cm	20 cm	Ø 1.8 mm	Ø 2.5 mm	Ø 3.5 mm
MD6232	62 cm	32 cm	Ø 2.5 mm	Ø 3.5 mm	Ø 4.0 mm
MD10010	100 cm	10 cm	Ø 1.5 mm	Ø 2.0 mm	Ø 3.0 mm

---

LS Conveyor platforms & brief specs w/ Thin solid PU plastic belt

Model	Length	Width	Load Capacity
LS-MB-32	146 cm or 180 cm	55cm	30 kgs.
LS-MB-45		68cm
LS-MB-62		85cm
LS-MB-100		123cm
